Product Features:
•Product Type = Switch
•Tactile = No
•Configuration (Pole-Throw) = Single Pole – Single Throw
•Series = TP
•Mount Angle = Vertical
•Termination Type = Wire Lugs
•Actuator Style = RoundElectrical Characteristics:
•Contact Rating = 20V Body Features:
•Mount Style = Panel
•Actuator Length (mm [in]) = 3.48 [0.137]
•Actuator Profile = Extended
•Actuator Color = Black
•Bushing Diameter = 10/48
•Case Material = Polyester
•Actuator Material = Polyamide Contact Features:
•Contact Plating = Silver Housing Features:
•Process Sealed = No
•Low Profile = No
•Bushing Style = Threaded Configuration Features:
•Operating Function = Normally Open, Momentary
•Ganged = No
•ESD Grounding Terminal = Without
•Actuator Force (g [oz]) = 50.00 – 400.00 [1.770 – 14.120]
•Number of Actuators = Single
•Illuminated = No
•Dust Proof = No
•Support Bracket = Without
•Snap Action = Without Industry Standards:
•RoHS/ELV Compliance = Not ELV/RoHS compliant
•Lead Free Solder Processes = Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder capable to 265°C Conditions for Usage:
•Temperature Rating = High Comment = No center terminal |
