RAMI AV-601 RADAR ANTENNA

Overview

Specifications

• Application: Airborne Low Range Radar Altimter
• Frequency: 4200-4400 MHz
• Impedance: 50 Ohms
• VSWR: 1.5:1 Max (4275-4325 MHz) / 2.3:1 Max (4200-4400 MHz)
• Polarization: Linear
• Pattern: Roll Plane(E): 45° min.
• Beam Widths: Pitch Plane (H): 40° min.
• Connector: TNC Female
• Max Height: .14″
• RF Power Capacity: 5 watts avg./500 watts max.
• FAA TSO: C87a
